NVIDIA, the biggest name in the graphics card market, continues to make a name for itself with the products developed with Ada Lovelace architecture. The company introduced Ada Lovelace RTX GPUs for laptops at the GPU Technology Conference (GTC) 2023.
RTX 4000 SFF is based on an AD104
NVIDIA combines an AD104 GPU with 20GB of GDDR6 memory at 16Gbps on a 160-bit bus. It comes with 20GB of GDDR6 memory with graphics card error correction code (ECC) with 6144 active CUDA cores, 192 Tensor cores and 48 RT cores. It is stated that the product, which has a single sensitivity of up to 19.2 TFLOPs, offers Tensor-based computing performance up to 306.8 TFLOPs.
NVIDIA RTX 4000 SFF key features;
GPU | NVIDIA RTX 4000 SFF |
---|---|
GPU Memory | 20GB GDDR6 with error correcting code (ECC) |
Display Ports | 4x mini DisplayPort 1.4a* |
Maximum Power Consumption | 70W |
Graphic Bus | PCIe Gen 4x16 |
form factor | 2.7″ H x 6.6″ L, dual slot |
On the other hand, NVIDIA has also updated all mobile workstation GPUs, introducing the RTX 5000, RTX 4000, RTX 3500, RTX 3000 and RTX 2000 Ada Generation. The introduced products perform in line with all consumer desktop graphics cards, with a few exceptions, including the RTX 3500 with 5,120 CUDA cores. The RTX 4000 SFF Island Gen workstation desktop GPU is listed at $1250.
Comparison list to give an idea;
RTX 5000 Island Laptop | RTX 4000 Island Laptop | RTX 3500 Island Laptop | RTX 3000 Island Laptop | RTX 2000 Island Laptop | |
CUDA Cores | 9728 | 7424 | 5120 | 4608 | 3072 |
Tensor Cores | 304 | 232 | 160 | 144 | 96 |
Acceleration Clock | ~2.19GHz | ~2.26GHz | ~2.25GHz | ~2.16GHz | ~2.36GHz |
memory clock | 18 Gbps GDDR6 | 18 Gbps GDDR6 | 18 Gbps GDDR6 | 16Gbps GDDR6 | 16Gbps GDDR6 |
Memory Bus Width | 256 bit | 192 bits | 192 bits | 128 bits | 128 bits |
VRAMs | 16 GB | 12GB | 12GB | 8GB | 8GB |
ECC | Partial (DRAMA) | Partial (DRAMA) | Partial (DRAMA) | Partial (DRAMA) | NO |
single precision | 42.6 TFLOPs | 33.6 TFLOPs | 23 TFLOPS | 19.9 TFLOPS | 14.5 TFLOPs |
Tensor Performance (FP8, Rare) | 681.8 TFLOPs | 538.0 TFLOPs | 368.6 TFLOPs | 318.6 TFLOPs | 231.6 TFLOPs |
NVENC/NVDEC | 2 of 2 | 2 of 2 | 2 / 1 | 11th | 11th |
Max TGP | 80-175W | 80-175W | 60-140W | 35-140W | 35-140W |
GPU | AD103 | AD104 | AD104 | AD106 | AD106 |
Architectural | Ada Lovelace | Ada Lovelace | Ada Lovelace | Ada Lovelace | Ada Lovelace |
Production process | TSMC 4N | TSMC 4N | TSMC 4N | TSMC 4N | TSMC 4N |
